| Model | Aluminum (Aluminium) Tube/Pipe |
| Material Grade | 1000 series: 1050,1060,1070,1080,1100,1435, etc
2000 series: 2011,2014,2017,2024, etc
3000 series: 3002,3003,3104,3204,3030, etc
5000 series: 5005,5025,5040,5056,5083, etc
6000 series: 6101,6003,6061,6063,6020,6201,6262,6082, etc
7000 series: 7003,7005,7050,7075, etc |
| Size | Outer Diameter:5-300mm |
| Wall Thickness: 0.3-80mm |
| Length: 10mm -6000mm |
| Standards | ASTM, ASME,EN, JIS, DIN,GB/T etc |
| Surface treatment | Mill finished,anodized,powder coating,Sand blast,etc |
| Surface colors | Nature, silver, bronze, champagne, black, gloden, etc
As customized |
| Status | T4 T5 T6 or other special status |
| Usage | aluminum profile for windows/ doors/ decoration/ construction/ curtain wall |
| Quality | China Nation Standard GB/T |
| Packing | Protective film +plastic film or EPE +kraft paper |
| Certificate | ISO 9001 2008 |
| MOQ | 1 tons. Usuall 12 tons for a 20 feet contaner; 24 tons for a 40 feet container. |
| Press Machine | 500-4000 tons all together 64 press lines |
| Moulding | 1. Using our moulds, no fee;
2. Using customer drawing, opening mould, usually about 5 tons the moulding fee is free;
3. Can be diguessed. |
Aluminum tubes are mainly divided into the following categories
According to the shape: square tube, round tube, pattern tube, special-shaped tube, global aluminum tube.
Divided by extrusion method: seamless aluminum tube and ordinary extruded tube
According to the accuracy, it is divided into ordinary aluminum tubes and precision aluminum tubes. Among them, precision aluminum tubes generally need to be reprocessed after extrusion, such as cold drawing and precision drawing and rolling.
According to thickness: ordinary aluminum tube and thin-walled aluminum tube
Properties: Corrosion resistance, light weight.
